ODM Turnkey PCB Assembly With IATF16949 Certificate SMT PCB

Name: ODM Turnkey PCB Assembly With IATF16949 Certificate SMT PCB
Brand: Sky-win
Price: 0.1 USD

Ask Latest Price

Video Channel

Brand Name :Sky-win

Model Number :PCBA-036

Place of Origin :Shenzhen,China

Certification :IATF16949

MOQ :100 piece

Price :$0.1- $4.9

Packaging Details :Carton

Delivery Time :5-10 working days

Payment Terms :L/C, D/A, D/P, T/T

Supply Ability :100000 pcs

PCB Material :FR-4, CEM-1, CEM-3, High TG, Rogers, Aluminum

Surface Finish :HASL, ENIG, OSP, Immersion Silver, Immersion Tin, Gold Plating

Min. Line Spacing :0.1mm

Assembly Type :SMT, Through-Hole, Mixed

Board Type :Single-Sided, Double-Sided, Multi-Layer

Component Type :SMD, Through-Hole, Mixed

PCB Size :Customized

Testing :AOI, X-Ray, Flying Probe, In-Circuit, Functional

Copper thickness :0.25OZ~12OZ

Product name :Printed Circuit Board

Layer :2 ~ 30 layers

Solder mask :Green. Red. Blue. White. Black.Yellow

Item :PCBA for electronic project

Contact Now

Add to Cart

View Product Description

OEM ODM Turnkey PCB Assembly With IATF16949 Certificate With FR-4 Material SMT PCB Manufacturer

Specification of Turnkey PCB Assembly

Article	Description	Capability
Sercive	PCB and SMT assembly with one-stop service
Files we need	PCB: Gerber files(CAM, PCB, PCBDOC)
	Components: Bill of Materials(BOM list)
	Assembly: Pick-N-Place file
Material	Laminate materials	FR4, high TG FR4, high frequency, alum, FPC
Board cutting	Number of layers	1-32
	Min.thickness for inner layers	0.003”(0.07mm)
	(Cu thickness are excluded)
Board thickness	Standard	(0.1-4mm±10%)
	Min.	Single/Double:0.008±0.004”
		4layer:0.01±0.008”
		8layer:0.01±0.008”
	Bow and twist	7/1000
Copper weight	Outer Cu weight	0.5-4 0z
	Inner Cu weight	0.5-3 0z
Drilling	Min size	0.0078”(0.2mm)
	Drill deviation	±0.002″(0.05mm)
	PTH hole tolerance	±0.002″(0.005mm)
	NPTH hole tolerance	±0.002″(0.005mm)
Solder mask	Color	Green,white,black,red,blue…
	Min solder mask clearanace	0.003″(0.07mm)
	Thickness	(0.012*0.017mm)
Silkscreen	Color	white,black,yellow,blue…
	Min size	0.006″(0.15mm)
E-test	Function Test	100% Functional test
	PCBA Testing	X-ray,AOI Test,Functional test
Pcb assembly	one-stop service electronic manufacxturer service
Component sourcing	Yes
Certificate	IATF16949,ROHS,UL
Delivery time:	PCB		3-12days
	PCBA		8-20days
Tolerance of pcb	±5%
Max size of finish board	450*450mm
MOQ	NO MOQ (1pcs)
Surface Finish	HASL,ENIG,immersion silver,immersion tin,OSP…
PCB outline	Square,circle,irregular(with jigs)
package	QFN,BGA,SSOP,PLCC,LGA

The Advantages of Turnkey PCB Assembly

Turnkey PCB assembly refers to the process of outsourcing the entire printed circuit board assembly process to a single supplier, including sourcing components, assembly, testing, and shipping. Here are some advantages of turnkey PCB assembly:

Time-saving: Turnkey PCB assembly saves time as it allows the customer to focus on other tasks and leave the assembly process to the supplier. The supplier takes care of all the details, including component sourcing, PCB fabrication, assembly, testing, and delivery, which can be time-consuming for the customer.
Cost-effective: Turnkey PCB assembly can be cost-effective as it eliminates the need for the customer to purchase and maintain expensive assembly equipment, hire personnel, and source components. The supplier can leverage economies of scale and pass the savings onto the customer.
Quality control: Turnkey PCB assembly ensures quality control as the supplier is responsible for all aspects of the assembly process, including component sourcing, assembly, and testing. The supplier has a vested interest in delivering high-quality products, as it affects their reputation and future business.
Single point of contact: Turnkey PCB assembly provides the customer with a single point of contact for the entire process, simplifying communication and reducing the risk of errors or miscommunications. This eliminates the need for the customer to coordinate with multiple suppliers and reduces the risk of delays or mistakes.
Customization: Turnkey PCB assembly can be customized to meet the specific needs of the customer. The supplier can work with the customer to select the right components, PCB fabrication, and assembly methods to ensure that the final product meets the customer's specifications.
In summary, turnkey PCB assembly offers numerous advantages, including time-saving, cost-effectiveness, quality control, a single point of contact, and customization. These advantages make turnkey PCB assembly an attractive option for customers looking to outsource their PCB assembly needs.
